Pneumatic Air Motors
Offering you a complete choice of products which include pneumatic air motor-reversible type, non reversible air motor, vane air motor-dam-2am-1 and high speed air motor-dam-4am.
Pneumatic Air Motor-Reversible Type
₹ 28600 / Piece Get Latest Price
| Brand | PEC |
| Usage/Application | INDUSTRIAL |
| Power | 0.5-2.5 hp |
| No Load Speed | <2000 RPM |
| Model | A050-1100 |
| Motor | 0.55 hp |
| Free Speed | 1100 rpm |
Minimum order quantity: 1 Piece
Air Motors are known for their rugged construction and reliability. Air Motors come in seven basic models up to 9.5 hp. Motor speeds are variable from 300 - 10000 rpm. Choose from Face, Foot, Flange and NEMA 56 C Standards. Air Powered Gear Motors are available in right angle and in line models offering a maximum torque range of 8 - 587 nm. Gear ratio available from 10:1 to 60:1 single reduction gear reducers.
Technical Specifications:
| Air Motor Model | Max. Power hp | Free Speed rpm at , 6.3 Kg/cm2 |
Stall Torque Nm Kg/ cm 6.3 Kg/cm2 |
O.A.L L mm |
Air Consum. m3/min |
Weight kg. |
| AR050 -17000 | 0.40 | 17000 | 0.7 | 120 | 0.4 | 1.2 |
| AR050 -12000 | 0.40 | 12000 | 1.1 | 120 | 0.4 | 1.2 |
| M2050-4000 | 0.40 | 4000 | 1.1 | 150 | 0.4 | 1.2 |
| AR050-3000 | 0.40 | 3000 | 4.4 | 150 | 0.4 | 1.6 |
| AR050 -2200 | 0.40 | 2200 | 6.4 | 150 | 0.4 | 1.6 |
| AR050-950 | 0.45 | 950 | 16 | 180 | 0.4 | 1.9 |
| AR050 -700 | 0.5 | 700 | 16 | 180 | 0.4 | 1.9 |
| AR050-540 | 0.5 | 540 | 29 | 180 | 0,4 | 1.9 |
Non Reversible Air Motor
₹ 18000 / Piece Get Latest Price
| No Load Speed | 70-12000 RPM |
| Maximum Air Flow | 6 bar |
| Port Size | 1/4" NPT |
| Speed | 70-12000 RPM |
| Weight | 1.94 - 5.2 Kg |
| Brand | PEC |
| Kw/Hp | 1.25 HP |
Minimum order quantity: 1 Piece
AIR MOTORS 1.25 HP NON-REVERSIBLE TYPE
Air Motors are known for their rugged construction and reliability.
|
AIR MOTOR MODEL
|
MAX.POWER HP
|
FREE SPEED RPM at 6.3 Kg/cm2
|
STALL TORQUE Nm at 6.3 Kg/cm2 |
O.A.L L mm
|
AIR CONSUM m3/min
|
WEIGHT Kg
|
|
A1025-12000 |
1.25 |
12000 |
3.7 |
152 |
1.0 |
1.94 |
|
A1025-2600 |
1.25 |
2600 |
17.1 |
209 |
1.0 |
3.04 |
|
A1025-2100 |
1.25 |
2100 |
21.2 |
209 |
1.0 |
3.04 |
|
A1025-600 |
1.25 |
600 |
74.40 |
259 |
1.0 |
4.1 |
|
A1025-400 |
1.25 |
400 |
111.60 |
259 |
1.0 |
4.1 |
|
A1025-120 |
1.25 |
120 |
372 |
309 |
1.0 |
5.2 |
|
A1025-70 |
1.25 |
70 |
637.7 |
309 |
1.0 |
5.2 |
Vane Air Motor-DAM-2AM-1
₹ 25000 / Piece Get Latest Price
| Model | DAM-4AM |
| Max Output Power | 1.30 Kw |
| Torque At Max Speed | 4 Nm |
| No Load Speed | 3000-10000 RPM |
| Maximum Air Flow | 6 bar |
| Power | 0.4-4 hp |
(Price varies from model to model)
Vane Air Motors are lightweight with a compact design and are easy to control. Vane Air Motor has no brushes to spark like electric motors and can be used in non-spark applications. Air motors can be found in ships, chemical plants, mines and power plants all over the word.
Technical Specifications:
|
Model |
Free Speed |
Power |
Power |
Stall Torque |
Air con. CFM |
Weight |
Air inlet |
|
DAM-1AM |
10000 |
0.33 |
0.45 |
0.31 |
20.50 |
0.82 |
1/8" |
|
DAM-2AM |
3000 |
0.69 |
0.93 |
2.00 |
30.00 |
3.10 |
1/4" |
|
DAM-4AM |
3000 |
1.30 |
1.70 |
4.00 |
78.00 |
3.95 |
1/4" |
|
DAM-6AM |
3000 |
3.00 |
4.00 |
8.00 |
128.00 |
9.10 |
½” |
High Speed Air Motor-DAM-4AM
₹ 45000 / Piece Get Latest Price
| Speed | 2000-6000 RPM |
| Model | DAM-6AM |
| Max Output Power | 3.00 Kw |
| Torque At Max Speed | 8 Nm |
| Free Speed | 100 RPM |
| Motor Power | 0.5 HP |
Minimum order quantity: 1 Piece
(Price varies from model to model)
Air motors are lightweight with a compact and are easy to control. Air motors have no brushes to spark like electronic motors and can be used in non-spark applications. Air motors can be found in ships, chemical plants, mines and power plants all over the world.
Technical Specifications:
|
Model |
Free Speed |
Power |
Power |
Stall Torque |
Air con. CFM |
Weight |
Air inlet |
|
DAM-1AM |
10000 |
0.33 |
0.45 |
0.31 |
20.50 |
0.82 |
1/8" |
|
DAM-2AM |
3000 |
0.69 |
0.93 |
2.00 |
30.00 |
3.10 |
1/4" |
|
DAM-4AM |
3000 |
1.30 |
1.70 |
4.00 |
78.00 |
3.95 |
1/4" |
|
DAM-6AM |
3000 |
3.00 |
4.00 |
8.00 |
128.00 |
9.10 |
½” |
